Renesas Electronics launches the industry‘s first programmable motor driver IC that achieves zero speed and full torque for sensorless brushless DC motors
Time:2023-12-10
Views:493
New technology enhances horsepower, efficiency, speed, and reliability; Simultaneously reducing costs and reducing circuit board space
Global semiconductor solution provider Renesas Electronics (TSE: 6723) announced today that it has launched the first sensorless motor driver IC series products suitable for brushless DC (BLDC) motor applications. This series adopts Renesas‘s patented new technology, which enables motors to achieve zero speed and full torque without sensors, pioneering the entrepreneurial world. The new motor driver IC enables Reza customers to design sensorless BLDC motor systems with greater horsepower and speed at a given torque. In addition, it also reduces power consumption, improves reliability, and reduces costs and circuit board space by reducing the number of components that designers need to use.
Renesas has released three new motor driver ICs using new technologies. Among them, RAA306012, as an independent 65V, 3-phase intelligent driver, can be paired with Renesas or various other MCUs; RAJ306101 integrates the Reza RX13T 32-bit MCU with RAA306012 in a single package, reducing circuit board space and cost, and improving reliability; RAJ306102 integrates the Reza RL78/G1F 16 bit MCU with RAA306012, bringing similar integration advantages.
The ability to achieve full torque at zero speed without the need for sensors is thanks to Reza‘s two innovative technologies: Enhanced Inductive Sensing (EIS), which can provide stable position detection when the motor comes to a complete stop; When the motor is running at an extremely low speed, the motor rotor position recognition (MRI) method is used. At higher speeds, the new motor driver IC adopts traditional methods. The new EIS and MRI algorithms both include cutting-edge technologies developed by Renesas that are currently being patented.
Davin Lee, The Vice President of the Advanced Analog Division at Renesas states: "The all-new sensorless design of motor driver ICs offers many advantages in terms of cost, space, power consumption, and reliability. Now, our customers can enjoy these advantages in systems that require zero speed and full torque. This industry initiative is the result of Renesas combining its technological strength with profound application knowledge to create a model of solutions that meet clear market demands."
Peter Koro, President and CEO of Domel Inc, a global supplier of motors, vacuum cleaner motors, blowers, and components š EC said, "We are very much looking forward to adopting sensorless technology in new products that used to require sensors. Renesas‘ breakthrough will enable us to build new products for customers based on optimal size, cost, and reliability."
Key Features of Reza‘s New Motor Drive IC
•Highly integrated, including drivers, power management, and current detection
•Adaptive and adjustable dead time drive efficiency improvement
•The charge pump can maintain a stable gate drive voltage under programmed settings
•Programmable gate drive voltage can drive N MOSFET and GaN FET
•Rich sensing blocks can achieve higher accuracy and wide speed RPM drive
• 16 programmable slew rate settings to minimize electromagnetic radiation
• Support all types of motor control algorithms such as trapezoidal, sinusoidal, and FOC
• Rich protection functions enhance system security
Successful product portfolio
Renesas has combined the new motor driver IC with numerous compatible components in its product portfolio to create a wide range of successful product combinations, including cordless vacuum cleaners and 20V cordless blade blowers. These "successful product combinations" are based on mutually compatible and seamlessly collaborative devices, with a technically validated system architecture that brings optimized low-risk designs to accelerate product launch speed. Renesas has now launched over 400 "successful product combinations" based on various products in its product lineup, enabling customers to accelerate the design process and push products to the market faster. For more information, please visit: renesas.com/win.
Supply information
RAA306012, RAJ306101, and RAJ306102 are now available on the market. RAA306012 adopts a 7mm x 7mm 48 pin QFN package. RAJ306101 and RAJ306102 are packaged in 8mm x 8mm 56 pin QFN. Renesas also provides evaluation kits for each new device. For more information, please visit www.renesas.com motorcontrols.
About Renesas Electronics
Renesas Electronics (TSE: 6723), with technology making life easier, is committed to building a safer, smarter, and more sustainable future. As a global microcontroller supplier, Renesas Electronics integrates expertise in embedded processing, simulation, power supply, and connectivity, providing complete semiconductor solutions. The successful product portfolio accelerates the launch of automotive, industrial, infrastructure, and IoT applications, empowering billions of connected smart devices to improve people‘s work and lifestyle.
|
