Design

Humidifier MCU scheme, atomizer MCU scheme

Time:2021-11-17 Views:2397
The company has a professional development team to help customers develop solutions free of charge

Humidifier MCU scheme, atomizer MCU scheme
    The product has built-in USB power supply equipment charging socket, adopts high-capacity battery and separate lithium protection, and can add functions such as timing, lighting, vibration and fan according to customer requirements. The scheme widely uses water replenishment instrument, aroma instrument and humidifier.

The scheme can be controlled by touch or key.
    The main control MCU is a CMOS MCU with low cost, high performance, 8-bit and full static flash. RISC architecture is adopted, with only 55 single word / single cycle instructions. The whole MCU is a dual clock system, with internal high-speed 20m and internal low-speed 32K clock. The instruction cycle can be set to 4 times or 2 times the clock cycle through option. The performance of the device is much higher than that of similar products at the same price. The instruction set which is easy to use and easy to remember greatly shortens the development time.









The above is ChipSourceTek MCU development engineer, humidifier MCU scheme and atomizer MCU scheme.
    ChipSourceTek focuses on the design and development of MCU application scheme, and provides 8-bit MCU, 32-bit MCU, audio, driver, MOSFET, charging management, lithium protection, touch control, DC-DC, AC-DC, PD protocol, MCU, 5g emission, special chip, etc.
